CNC high-speed cylindrical grinding machine

Machine Features：

★X-axis and Z-axis of this series of machine tools adopt imported FANUC or SIENENS two-axis CNC system, built-in PLC,

Color LCD display.

★The feed of the grinding wheel and the movement of the worktable are driven by the AC servo motor through the ball screw, and the feed of the grinding wheel is guided

The rail adopts imported linear rolling guide, and the worktable adopts

Hydraulic oil forcibly lubricates the flat-V guide rail to ensure accurate and sensitive feeding.

★The grinding wheel frame motor adopts AC frequency conversion speed regulation device, which can basically realize constant linear speed grinding.

★The grinding wheel spindle bearing adopts dynamic and static pressure bearing, which has high rotation precision and good rigidity, and can realize the forming and grinding of wide grinding wheel.

★The head frame motor adopts AC variable frequency speed regulation device to realize stepless speed regulation.

★The tailstock sleeve has hydraulic telescopic function.

★The machine is equipped with independent electrical cabinet, fuel tank and water tank

★The machine tool is equipped with a full protective cover, and the operation is safe and reliable. Easy on-site management

★It is equipped with an automatic end face outer circle measuring instrument for online detection to realize a closed-loop automatic grinding cycle.

TECHNICAL SPECIFICATIONS

Height of center 270mm

Distance between centers 1050/2100mm

Max.diameter to be ground φ500mm

Max. length to be ground 1000/2000mm

Max. weigth of workpiece 1000kg

Dimension of Max. grinding wheel φ750×（20-125）×φ305mm
